CS Q-LEAP™ – The next step calibration system

A technical breakthrough for sensor calibration.
Future proof solution for the digital sensor age.

For analog and all‑digital sensors

  • powerful analog signal inputs
  • various integrated digital DUT inputs
  • software flexibly adaptable to new DUT types
  • traceable to PTB and other national laboratories

For a complex sensor world

  • intelligent DUT database
  • information about any sensors and measurement chains can be stored
  • a wide range of additional information for user support

For consistent
availability

  • tested long-term stability reduces the calibration cycles of the system
  • an intelligent service concept minimizes downtime

For simple data exchange

  • Calibration data available as XML files
  • Integration of eCal™ as a flexible tool for data merging and transformation

CS Q-LEAP™ systems are the solution for calibration and testing of sensors as well as measurement chains using dynamic methods.



HERO controller for the CS Q-LEAP calibration system

HARDWARE

HERO™ – the heart of CS Q-LEAP™

• versatile output options

• interfaces for data import and export

• optional interface to external databases

• primary calibration with laser vibrometers



SOFTWARE

Full control with various operating modes and extensive sensor communication

• standardized yet open software

• easily customizable

• integrated database



COMPONENTS

Wide range of possible exciters and suitable power amplifiers

• wide range of typical DUTs

• modular upgrades

• efficient maintenance

• calibration according to ISO/IEC 17025



A quantum leap in the world of sensor calibration
and as compared to the last generation of CS systems.

  • systems are made for analog as well as digital sensors
  • new GUI was modernized visually as well as technically
  • increased system performance and more features thanks to the new, powerful vibration control system HERO™
  • systems allow a flexible frequency range and offer comprehensive software operating modes
  • easily customizable and offers modular upgrades
  • future-proof: CS Q-LEAPTM systems are developed for the future, flexible and boundlessly extendable
  • integrated database enables easy DUT management
  • versatile output options for calibration results provide a strong basis for calibration certificates

Customer statements

"We are extremely happy with our purchase.
We look at this new tool as a critical step in our ability to develop the most robust and competent products for consumption by our customer base. [...] We could not have asked for more from SPEKTRA."

Dave Change, CTO and Vize President
Dytran Instruments

read USER STORY now

"[...] Above all, however, the system is based on a completely new software architecture, which ensures the transparency and traceability of the measurements. In the months that I was allowed to work with this new system, I was able to convince myself that this system meets the
highest requirements of a NMI and will meet current and future needs.. [..]"

Christian Hof, Dr. ès. sc.
Long-time Head of acoustics and vibration labs
Eidgenössisches Institut für Metrologie METAS


Download Statement

What's behind?

Michael Mende product manager at SPEKTRA – explains in detail.

The «Q» stands for ...

CS Q-LEAP 3D Logo

Quality

... of products and services from over 26 years of experience with sensor calibration. Our hardware, systems and services are accredited and were all developed in-house. Thanks to high quality materials and manufacturing, we can ensure traceability and warranty at any time.

Quantity

... as in the amount of possibilities to measure and calibrate. The CS Q-LEAPTM systems enable to test an extensive range of dynamic physical quantities – from acceleration and shock down to dynamic force… and even more to come! With the new generation of systems, the range of DUTs you can calibrate is almost endless.

Qualified

... experts at your side to find the best fitted solution to your challenge and task. Developing advanced products is our top priority. To achieve this, we take advantage of the creativity of our employees and our know-how and expertise, so that we can set new quality standards together with our customers.

Quick

... on the market and quick for our customers. First, we are agile in response to customers’ needs and market trends. Moreover, the CS Q-LEAPTM systems are fast and time saving with regard to installation, commissioning, calibration setup, calibration time, evaluation, maintenance and many more.

Key features

  • wide range of typical DUTs
  • flexible frequency range
  • comprehensive software operating modes
  • future proof and boundlessly extendable
  • one vibration control system, many applications
  • traceable to PTB (German National Metrology Laboratory)
  • fair and extensive support and service contract
  • technical support and recalibration available worldwide
  • specific accessories like cables, adapters or tools
    Price list

Software highlights

  • extensive operating modes
  • embedded sensor database
  • integrated software for the generation of calibration certificates
  • easy data exchange with third-party applications
